High Flow

High Flow Filter is a large diameter, single open ended pleated cartridge filter. With a 6″/152mm diameter, large filtration area, and high flow rate up to 90mÑ/hr. It can be widely used in a wide variety of industry with less downtime for change-out.

Features and Benefits

  • High density pleated filter type resulting in a high filtration area, high flow rates, longer service life, and high dirt holding capacity.
  • Multi-layered design provides gradient filtration.
  • Internal PP core guarantees no distortion and resists higher
  • reverse differential pressure.
  • Ergonornically designed handle facilities fast and easy
  • Installation and remove without special tools.



Materials of Construction

Filter MediaPleated Polypropylene depth structure
Rein bonded glass fiber/Polyester support
Support/DrainagePolypropylene
Polyester
End CapsGlass filled polypropylene
CorePolypropylene
Outside MaterialPP Cage (HFPP150 Series)
PET Net (HF150 Serise)

Recommended Operating Conditions

Max. TemperaturePP: 80°C
GF: 121°C
Max. Pressure0.40 Mpa/21°C HFPP150 (PP Cage)
0.38 MPa/21°C HF150 (PET Net)
0.15 MPa/80°C

Flow Rate

Length20″40″60″80″
Design Flow Rate15 m3/h30 m3/h45 m3/h60 m3/h
Max Flow Rate30 m3/h60 m3/h90 m3/h120 m3/h

Retention Ratings

Polypropylene (PP)1.0, 2.0, 5.0, 10, 20, 40, 70, 90μm
Glass Fiber (GF)0.8, 1.0, 3.0, 5.0, 15, 25μm

Retention Characteristic

Particle SizeFiltration Efficiency HF150NB
PP0.8PP1.0PP2.0PP3.0PP5.0PP10.0PP20.0
≥1μm99.89%99.82%95.00%86.97%79.86%42.23%24.38%
≥2μm99.97%99.87%98.64%96.84%90.09%70.49%40.09%
≥5μm100.00%99.93%99.90%98.86%98.36%x82.26%76.66%
≥8μm100.00%100.00%99.97%99.20%98.88%95.25%82.60%
≥10μm100.00%100.00%100.00%99.58%99.39%98.18%89.42%
≥12μm100.00%100.00%100.00%99.78%99.57%98.76%97.41%
≥25μm100.00%100.00%100.00%100.00%100.00%99.34%99.14%



Remarks: The testing particle is made by mixed solution of standard silica
